snow thrower that connects to a plow!
Rammy Snow Thrower ST30 ATV is a snow thrower intended for attachment to an ATVs snow plow. It is an agile solution for snow removal, allowing convenient and quick snow clearing and making sure snow banks do not become a problem as the winter lingers on.
- Snow Thrower ST30 ATV ejects snow to a distance of up to 15m, preventing snow bank formation.
- Directly compatible with Rammy Plow W165 ATV PRO.
- The 306cm3 Briggs&Stratton winter engine with electric start ensures that snow clearing from yards and roads can be managed effortlessly and quickly.
- The Snow Thrower comes with electrically operated, 160-degree snow discharge chute.
- Winter begins with plowing, ends with snow blowing!
Features
Snow Thrower for plow
Rammy Snow Thrower ST30 ATV is attached to the plow with 4 screws. The impeller is equipped with rubber blades that absorb shocks and function as snow mover/fuse.
Snow Thrower over the entire plow width
Rammy Thrower Plow ATV is an ATV-mounted plow and Snow Thrower combination.
Light and compact structure
The plow and Snow Thrower can be lifted using the ATV’s winch. Especially with the front-mounted accessory frame, the plow rises to a high position, leaving ample space for working and ground clearance for travel.
A functional whole
Where the plow’s qualities end, the Snow Thrower’s qualities begin. Snowbanks are no longer formed. The ST30 works with frosty snow, wet snow does not go through.
Designed down to the last detail
All details have been well thought out, including functionality, safety, maintenance, and storage.
Standing support for storage
The Snow Thrower takes up little space in storage. A pivoting support leg has been provided for storage and installation. The required storage space is W39xL76xH87cm.
Technical Information
| Working width | Depends on the plow, typically 1.2-2m. |
| Weight | 70 kg. |
| Dimensions | W39 x L76 x H87 cm. |
| Engine | Briggs&Stratton 1450 SnowSeries. Cubic volume 306 cm3, torque 20 Nm. Tank volume 3.0 L. Manual/electric (230 V) starting. |
| Impeller | 1-stage, 4-blade. Rubber blades absorb shocks and transfer the snow inside. Steel throwing plates 4 pcs. Impeller Ø 300mm. |
| Transmission | 2 x V-belt, belt tensioner pulley. |
| Snow throwing distance | Up to 15 m. |
| Remote control | Electronic remote control. Electricity is generated by the snow thrower’s engine. – ON/OFF switch – Throwing chute rotation RIGHT/LEFT 160 degrees. |
| Attachment to plow | Bottom attachment to plow lower edge by two nuts. Top end to plow top edge by two screws. |
| Rising/lowering | With the ATV’s winch. A counterweight is recommended for the ATV to balance the front load. |
| Skis/sliding surface | Special wear-resistant steel. |
| Capacity | 750 m3/h frosty snow. |
| Consumption | 1-2 L/h. |
| Standard equipment | – Snow removal tool – Pull cord start – Electric start 230V – Electronic remote control – Plow mounting hardware – Remote control fasteners to ATV’s handlebar – Adapter for plow arch – Stand for storage and maintenance |
| Price | 2890 € incl.. VAT 25,5 % |
| Warranty | 2 years. Rammy Snow Thrower ST30 ATV is a CE marked product. The snow thrower is patented. |
